My LED conversion as well as IMPORTANT information about changing the dome lights!

[maxmar04]

So today in installed a TON of various blue LEDS from v-leds.com in my car. I love it, it looks really nice. V-leds is a great company to deal with and has amazing prices IMO. I changed the courtesty lights, footwell lights, and front/rear dome/map lights to blue and the license plate lights to a "cool white". they blue is a very nice shade of deep blue and the white license plate is SUPER bright white with a tiny hint of blue. Overall it looks really nice and I'm very pleased.

HOW TO FINALLY CHANGE TO DOME LIGHTS!!!

From what I can tell, i am the first person to figure out how to change the interior dome lights to aftermarket. as you may know, Hyundai does not use a standard bulb in the dome lights that can be replaced, but i have figured it out! its not that hard actually....

when inside the front or rear dome/map light housing, you will see 3 wires attached to the already existing LED circuit board.....

cut and strip the wires or de-solder them from the led board. (as you can see, i cut in the middle of the wires and stripped and soldered from there.

you are going to splice the black and yellowish (im color deficient so i have no idea of this is yellow) wires from the dome light together and connect that connection to the negative/black connection of your light. then you are going to connect the red wire from the dome light to your LEDs red/positive connection.... (sorry if that didnt make much sense, im extremely tired. heres a diagram to show how simple this is.)

ENJOY

i believe this is 12V of straight power so if your LED doesn't have a resistor built in, you might want to be careful.

sorry for the extremely crapy pic, they are much brighter in person.

these are the LEDs i used



[maxmar04]

Hmm, I thought this little tutorial would get some attention considering all of the people who converted to all LED's and were waiting on the dome lights.....



[scottdk]

You did a good job and I see you took your time to make your lighting the way you want it. I think if the Genesis 4.6 didn't come with dome light LED's factory, more people would probably be interested. LED replacement for other applications such as the puddle lights are a good idea, which I've done them all



[Ruissimo]

FWIW... I read this, found it really interesting, and chalked it up to something I probably wouldn't dare try on my own car. LOL

Good job though! I love to see DIY mod instructions... keep 'em coming!



[maxmar04]

FWIW... I read this, found it really interesting, and chalked it up to something I probably wouldn't dare try on my own car. LOL

Good job though! I love to see DIY mod instructions... keep 'em coming!

Thanks. And dont worry, ill get to that plastidip DIY video HOPEFULLY this weekend. i cant even describe how busy ive been.



[dbstone]

Where can we purchase these led's for the map lights?



[187WeaponRR]

HI thanks for the info but I have a question what leds do you replace it with? what housing did you use? if IDK if my led have resistors built in what resistor do i use and what size? Thanks any help in advance



[187WeaponRR]

Also if you have any pics of the parts you used that would be great. Lastly I bought this kit off ebay it contained Step/Courtesy Lights, Trunk/Cargo Lights, Footwell Lights, License Plate Lights (License Plate Lights will be WHITE).
THIS IS THE LED LIGHT KIT I GOT
My LED conversion as well as IMPORTANT information about changing the dome lights!

If you look at the picture it shows the over head dome light in the purple color?
I have a 2009 Genesis sedan 4.6l with the technology package
